Product Overview
The Intex Krystal Clear SX2800 is a sand filter pump designed for above-ground pools, offering efficient filtration and a 6-way valve for multiple functions. It includes a 24-hour timer for automated operation, ensuring clean and safe pool water. Compatible with various Intex pool models, it requires silica or glass sand for optimal performance. The pump operates at 220-240V with a flow rate of 10.5 m³/h, making it a reliable choice for maintaining pool hygiene and clarity.
1.1 Parts Reference
The Intex Krystal Clear SX2800 Sand Filter Pump includes essential components for proper function. Key parts are the motor, 6-way valve, sand filter tank, and pre-filter assembly. Additional items include the air jet valve, strainer grid, plunger valve, and O-rings for sealing connections. The pump comes with hoses, clamps, and adapters for pool compatibility. For assembly, tools like a Phillips screwdriver may be needed. The parts reference ensures users can identify and replace components as needed. Proper identification of parts is crucial for safe and efficient setup, operation, and maintenance of the pump, ensuring optimal pool filtration and longevity of the system. Always refer to the manual for part numbers and ordering details.
1.2 Product Specifications
The Intex Krystal Clear SX2800 Sand Filter Pump operates at 220-240V, 50Hz, with a power consumption of 450W; It has a maximum flow rate of 10.5 m³/h and a maximum head pressure of 7.5 meters. The pump requires No. 20 silica sand (55 kg) or glass sand (38 kg) for optimal filtration. It features a 6-way valve for multiple functions, including filter, backwash, rinse, recirculate, drain, and close. The pump is IPX4 rated for weather resistance and designed for above-ground pools. Compatible with Intex Ultra XTR Frame Pools, it ensures efficient and reliable pool water circulation and filtration.
Setup Instructions
The Intex SX2800 setup involves assembling the pump, mounting it level, and connecting hoses. Requires a team, Phillips screwdriver, and sand loading for optimal filtration performance.
2.1 Assembly Requirements
Assembly of the Intex SX2800 requires a Phillips screwdriver and a team of at least two people. Ensure all parts, including the air jet valve, strainer grid, and hose connections, are included and properly fitted. No additional tools are needed beyond a screwdriver. If purchased separately, order missing parts from Intex. Proper assembly ensures safe and efficient operation. Follow the manual’s detailed instructions to avoid leaks or damage. Incorrect assembly can lead to performance issues or safety hazards. Double-check all connections before initial use to ensure everything is securely fastened and aligned correctly.
2.2 Pump Location and Mounting
Position the Intex SX2800 pump on a level, stable surface near the pool. Ensure it is at least 6 feet away from any electrical outlets to reduce shock risks. For non-Intex pools, connect hoses securely with large clamps. The pump must be installed on a firm, even base to prevent vibration and ensure proper operation. Keep it away from sources of heat and flammable materials. Proper grounding is essential; consult local electrical codes for compliance. Mounting on uneven ground may void the warranty and lead to operational issues.
2.3 Motor Pre-Filtering Assembly Setup
Before operating, ensure the motor pre-filtering assembly is correctly installed. The strainer grid prevents large debris from entering the pump, protecting it from damage. Install the strainer, nozzle, and plunger valve before inflating the pool liner top ring if applicable. Refer to the parts list for specific component identification. Secure all connections tightly to avoid leaks. Ensure the air jet valve is not covered during normal operation or while the pump is running. Proper assembly ensures efficient filtration and prevents potential damage. Always follow the manual’s instructions for a safe and effective setup.
Operating the Pump
The Intex SX2800 operates with a 6-way valve, enabling functions like filtration, backwash, and drain. Use the 24-hour timer for automated operation, ensuring efficient pool maintenance.
3.1 Filter Mode Operation
The Intex SX2800 operates in Filter Mode by circulating pool water through the sand filter to remove impurities. To activate, ensure the 6-way valve is set to the “Filter” position. The pump will draw water, push it through the sand, and return clean water to the pool. For optimal performance, run the pump daily according to the recommended cycle times. Always ensure the valve is not in the “Closed” position while the pump is running to avoid damage. Regularly monitor the system to ensure proper filtration and clean water quality. Adjust the timer or manual operation as needed for consistent pool maintenance.
3.2 Timer Mode Operation
The Intex SX2800 features a 24-hour automatic timer for convenient operation. Set the desired operating hours using the timer button, and the pump will run accordingly. To view preset hours, press the timer button while the pump is running; the display will flash the set time for 10 seconds. Note that the timer includes an additional 10 minutes beyond the actual setting. This mode allows for consistent filtration without manual intervention. Ensure the timer is correctly programmed to maintain optimal pool water quality. Always refer to the recommended operating times for your pool size to ensure efficient performance. This feature enhances ease of use and energy management.
Maintenance Guidelines
Regularly clean and inspect the filter, ensuring sand levels and quality are maintained. Replace sand every 5 years or as needed. Check for worn parts and winterize properly to prevent damage.
4.1 Sand Loading and Replacement
For the Intex SX2800, use No. 20 silica sand or glass sand with particles sized 0.45–0.85 mm and a Uniformity Coefficient < 1.75. Load 23 Kg (50 lbs) of silica sand or 16 Kg (35 lbs) of glass sand. Ensure the center pipe hub is securely centered and fastened before adding sand. Improper assembly can cause valve failure, leading to injury or damage. Replace sand every 5 years or when filtration efficiency decreases. Always follow the manufacturer's guidelines for sand type and quantity to ensure optimal performance and longevity of the filter system.
4.2 Regular Cleaning and Inspection
Regularly inspect the Intex SX2800 sand filter pump for damage or wear. Clean the strainer basket weekly by removing large debris. Every two weeks, backwash the filter to remove trapped contaminants. Check and replace O-rings and gaskets as needed to prevent leaks. Inspect the pump motor and electrical connections for damage or corrosion. Lubricate valve O-rings periodically for smooth operation. Clean the sand filter every 1-2 months by backwashing or rinsing. Ensure all components are secure and functioning properly to maintain optimal performance and extend the lifespan of the pump.
Winterization and Storage
To winterize the Intex SX2800, drain all water from the pump and filter system using the drain plugs. Disconnect and store hoses, ensuring they are dry and protected from freezing. Clean the sand filter and leave it to dry completely. Store the pump in a dry, covered area away from direct sunlight and freezing temperatures. Apply a rust-inhibiting spray to metal parts if necessary. Ensure the pump is fully dry before storage to prevent mold or corrosion. Proper winterization extends the lifespan of the pump and ensures it operates efficiently when reused.
Safety Rules
Always follow safety guidelines to prevent accidents. Keep the pump at least 6 feet away from electrical outlets and avoid placing portable appliances near the pool. Never cover the air jet valve with the valve cap during operation. Ensure the pump is installed correctly to avoid electric shock or injury. Do not use the pump with permanently installed pools—only with storable pools. Follow all chemical manufacturer instructions to prevent pool liner damage. Regularly inspect the system for wear and tear. Keep children away from the pump and pool area when the pump is operating. Always unplug the pump before performing maintenance or repairs.
Troubleshooting Guide
Common issues include the pump not turning on, low water flow, or sand filter clogging. Check power supply, ensure proper sand levels, and inspect for blockages.
If the motor overheats, allow it to cool before restarting. For persistent problems, refer to the manual or contact Intex support.
7.1 Common Issues and Solutions
The most frequent issues with the Intex SX2800 include the pump not starting, low water flow, or excessive noise. If the pump fails to start, check the power connection and ensure the GFCI/RCD breaker isn’t tripped. For low flow, inspect the filter for clogs and ensure proper sand levels; Noise may indicate worn or loose parts, which should be tightened or replaced. Regular maintenance, such as cleaning the filter and checking valve settings, can prevent these issues. Always refer to the manual for detailed troubleshooting steps and solutions.
Advanced Features
The Intex SX2800 features a 6-way valve for versatile operations and a 24-hour automatic timer, enabling scheduled filtration for convenient pool maintenance and energy efficiency;
8.1 6-Way Valve Functions
The 6-way valve on the Intex SX2800 offers six distinct functions: filtration, backwash, rinse, recirculate, drain, and close. These modes allow for effective water circulation, cleaning the sand filter, and draining the system. The filtration mode pushes water through the sand for purification, while backwash reverses flow to clean the sand. Rinse ensures no dirty water remains after backwashing. Recirculate bypasses the filter, and drain empties the system. The close function stops all water flow, preventing damage during maintenance. This versatile system ensures optimal pool maintenance with minimal effort.
8.2 24-Hour Automatic Timer
The Intex SX2800 features a built-in 24-hour automatic timer, enabling users to set specific operating times for the pump. This timer ensures consistent water circulation and filtration, maintaining clean pool conditions with minimal effort. The timer includes a 10-minute additional setting beyond the selected duration for enhanced efficiency. Users can preset the pump to run during off-peak hours or specific cycles, optimizing energy use. The timer also displays remaining operating hours, providing clear status updates. This feature simplifies pool maintenance, allowing for automated operation and consistent water quality throughout the day.
Sand Filter Information
The Intex SX2800 requires No. 20 silica or glass sand with a particle size of 0.45–0.85 mm and a Uniformity Coefficient under 1.75. Sand quantities vary per model.
9.1 Recommended Sand Types and Quantities
The Intex SX2800 requires high-quality filtering media for optimal performance. Recommended sand types include No. 20 silica sand or glass sand, with a particle size range of 0.45 to 0.85 mm (0.018 to 0.033 inches). The Uniformity Coefficient must be less than 1.75 to ensure proper filtration. For the SX2800 model, the recommended sand quantity is 55 kg (120 lbs) of silica sand or 38 kg (85 lbs) of glass sand. These specifications ensure efficient water filtration, maintaining clean and safe pool conditions. Always use the correct type and quantity of sand to avoid performance issues and potential damage to the filter system.
Electrical Requirements
The Intex SX2800 operates on 220-240V, 50Hz, with a power consumption of 450W. It requires a grounded electrical outlet protected by a GFCI/RCD circuit breaker. Ensure the pump is installed at least 6 feet (1.8 meters) away from any electrical outlets to reduce shock hazards. The unit is IPX4 rated, meaning it is splash-resistant but not fully waterproof. Always use the provided power cord and avoid modifying it. Do not operate the pump near water without proper grounding. Follow all local electrical codes and safety guidelines to ensure safe and reliable operation. Proper electrical setup is crucial for performance and safety.
Pool Compatibility
The Intex SX2800 is designed for compatibility with Intex Ultra XTR Frame Pools, including rectangular and round models. It works seamlessly with pools like the Ultra XTR Rectangular Frame (975×488 cm) and Ultra XTR Round Frame (732 cm). The pump is also suitable for other above-ground pools with 1-1/4″ (32mm) connections. For non-Intex pools, ensure the inlet/outlet fittings match the pump’s specifications. Always refer to the pool’s manufacturer guidelines for compatibility and connection requirements. Proper pairing ensures optimal performance and extends the life of both the pump and pool system.
Warranty and Support
Intex provides a limited warranty for the SX2800 Sand Filter Pump, covering manufacturing defects for a specified period. For warranty claims, contact Intex Consumer Service at 1-310-549-8235 (Monday-Friday, 8:30am-5:00pm PT). Proof of purchase is required. Damage from improper use, freezing, or neglect is not covered. For technical assistance or missing parts, visit www.intexcorp.com. Authorized service centers are listed separately. Always follow safety guidelines and maintenance instructions to ensure warranty validity and optimal product performance.
Additional Resources
For further assistance, Intex offers downloadable PDF manuals on their official website. Visit www.intexcorp.com for detailed guides, troubleshooting tips, and maintenance instructions. Additional resources include setup videos, product specifications, and safety guidelines. Contact Intex Consumer Service for technical support or warranty inquiries. Stay informed about product updates and safety alerts by referring to the provided materials. These resources ensure optimal performance and longevity of your Intex Krystal Clear SX2800 Sand Filter Pump.
